100mm x 39mm Raised Aluminium Heavy Duty Expanded Metal Sheet | 4mm Thick

Description

100mm x 39mm Raised Aluminium Heavy Duty Expanded Metal Sheet

This 100mm x 39mm x 4mm expanded metal mesh is a heavy-duty, practical sheet material suitable for customers who need strength, rigidity and long-lasting performance in general-use applications. Made by slitting and stretching a solid metal sheet, this mesh forms a single-piece structure with no welds, giving it excellent durability and resistance to impact, bending and fatigue. The large diamond-shaped openings provide a strong and open pattern that is useful across a wide variety of non-architectural tasks.

The mesh has a long-way pitch of 100mm and short-way pitch of 39mm, producing an open and easy-to-work-with profile. With a visual open area of 40% and an airflow open area of 64%, this mesh is ideal for jobs that require a strong barrier while still allowing air, light or water to pass through. Common uses include machinery guarding, agricultural equipment repairs, screening, animal enclosures, compost bays, protective covers, DIY builds, gates, fences and workshop projects.

At 4mm material thickness, this is the heaviest and strongest version available in this pattern. In aluminium it weighs approximately 7.5 kg/m², making it easier to handle for general jobs while still offering excellent rigidity. The mild steel option weighs around 21.7 kg/m², providing a substantially stronger material suited to high-wear, high-load environments. Mild steel sheets can also be painted, primed or finished as needed for outdoor use.

This expanded metal mesh can be cut using angle grinders, power cutters or heavy-duty tin snips depending on the material chosen and the user’s tools. It can also be drilled, bolted, welded or fixed to timber or metal frames, making it a versatile option for workshops, tradespeople and DIY users. The coarse opening size ensures that the mesh is not easily clogged by debris, making it suitable for livestock-related setups, ventilation, tool storage racks and screening where visibility is still required.

Specification Of This Mesh:

• Metal – Aluminium
• Pitch – 100mm long way x 39mm short way
• Thickness – 4mm thick
• Weight – 7.5 kg/m2
• Visual Open Area % – 40%
• Air Flow Open Area – 64%

Why Choose The Mesh Company?

The Mesh Company is the small order, rapid delivery arm of Locker Group.  Our group have been in the mesh industry for over 150 years.

We are one of the UK’s most trusted metallic mesh suppliers because:

• Quality products: We offer high-quality products that are designed to meet the needs of a wide range of customers.
• Wide range of products: We are known for offering a wide range of products, including mesh, fencing, netting, and other related products.
• Experienced staff: Our staff are knowledgeable, experienced, and can provide expert advice and assistance to customers. This can be especially helpful for customers who are unsure about which product to choose or who have specific requirements. We also regular write blogs and help guides to help explain what our materials can be used for.
• Competitive prices: We are sure that our prices are always the lowest around. This makes us an attractive option for customers who are looking for a cost-effective solution.
• Customer service: The Mesh Company place a high priority on service and offer excellent support and assistance to our customers. This can help to ensure that you will have a positive experience when working with The Mesh Company.

What Else Is Available?

The Mesh Company supplies this heavy-duty expanded metal mesh with fast dispatch and no minimum order quantity, making it ideal for one-off tasks, repairs, fabrication jobs and small builds where immediate availability is essential. We focus on offering practical, accessible material solutions for trade users, hobby fabricators and maintenance teams who need robust mesh without committing to full-sheet orders. For customers working on architectural or façade-led applications, lighter mesh thicknesses such as 2mm and 3mm—as well as specialist finishes—are available through our sister company, Locker Architectural.

Locker Architectural has extensive experience supplying expanded metal for large-scale projects, including a large-scale development in Manchester, where this 100mm x 39mm profile was used as part of the exterior scheme. While The Mesh Company provides convenient quantities for general-purpose use, Locker Architectural remains the dedicated supplier for full architectural specification, fabrication support and large project consultation.

FAQs For This Product

What Tools Do I Need To Cut 4mm Expanded Metal Mesh?

Cutting this heavy-duty mesh requires strong tools due to its 4mm thickness. For aluminium sheets, an angle grinder, circular saw with a metal-cutting blade, or heavy-duty tin snips may be suitable depending on your setup. For mild steel, we recommend an angle grinder or powered metal-cutting saw for clean and controlled cuts. Always wear appropriate safety equipment, as expanded metal can have sharp edges when cut. We would cut this on our specialist aluminium wall saw.

What Is This Mesh Commonly Used For?

This mesh is ideal for non-architectural, practical applications where strength and rigidity are required. Typical uses include machinery guards, tool storage cages, agricultural repairs, dog runs, security panels, ventilation covers, compost bays, screening, and general workshop fabrication. The large 100mm x 39mm diamond openings offer good visibility and airflow while still providing a strong physical barrier.

Can This Mesh Be Welded Or Fixed To Frames?

Yes. Both aluminium and mild steel versions can be fixed to frames using screws, bolts, rivets or clamps. Mild steel can be welded directly to steel frameworks, making it useful for fabrication jobs and permanent fixtures. Aluminium can be welded using specialist aluminium welding equipment or simply bolted to a wooden or metal frame for lighter-duty applications. The mesh’s single-piece expanded design ensures secure attachment without weak points.
